• ● Faster feed speeds of up to 36 meters a minute are standard.
• ● Programmable controller provides convenient depth of cut settings.
• ● Adjustment of each spindle can be easily performed using the front adjustment level.
• ● Exclusive, separate adjustment of the vertical spindles and the feeding table allows the feeding table to be positioned extremely close to the cutterhead to provide added cutting stability.
• ● The full safety enclosure serves as a chip guard and helps to reduce noise.
• ● Each spindle is driven by an individual motor for powerful drilling and easy control.
• ● Pneumatic pressure of the feed rollers can be easily set to provide an outstanding feeding effect.
• ● Table surface is hard-chrome plated for maximum wear resistance.。
• ● All manually adjusted turning parts are housed in dry bearings for oil-free lubrication.
• ● Automatic lubricator is provided to supply oil to the running parts.
• ● One-piece, cast iron or steel welding machine frame is specially heat treated for maximum stability and rigidity by standard configuration.
• ● Powered elevation of left vertical spindle provides convenient adjustment.

Greasing to all critical parts is conveniently made by the centralized arrangement of lubrication points.

Feed Table

The entire feed table is normalization heat treated for maximum stability. Fence adjustment is quickly accomplished by means of a quick-setting lever.

All spindles are precision constructed and specially heat treated to provide maximum cutting stability and permanent accuracy. They are water and dust-proof. Standard spindle speed is 6,000 RPM.

Adjustment of all spindles is easily effected from the front. The adjustment points are all at the same height, for more convenient and faster adjustment.

The feed rollers are driven through a combination of universal shafts and gearbox, ensuring no loss of power transmission. A smooth feeding effect is assured. The heavy duty gearbox has no backlash and provides powerful and accurate feeding performance.

Width and thickness setting can be easily set using the programmable controller. The desired values for width and thickness can be conveniently pre-set and are displayed on an LED. The speed is inverter controlled, and all electrical components meet CE standards.

The mechanism provides added smoothness for short workpiece feeding. The auxiliary feed rollers are power driven for effortless feeding effect, and are liftable for convenient cutter change or setup.

Provides positive feed effect for short and narrow stock by 3 pneumatic controls.

Utilizing housing bearings, the reliable hydro-clamping system ensures consistent quality across the entire workpiece. The unit performs admirably even during high-speed continuous operation. The spindles can be adjusted axially even if the housing bearings are locked.

The remote-controlled straight jointers provide accurate operation with high repeatability. They help ensure a long service life and super surface quality. (Opt.)

The program computer system allows for the programming and storing of 24 sets of dimensions. When the desired dimensions are entered, the left and top spindles automatically move to the corresponding position. This system eliminates the need for trial runs.
